| Technical Details | |
|---|---|
| Form factor | U.2, 2.5” x 15mm |
| Interface | PCIe NVMe Gen5 x4 (backward compatible with Gen4) |
| Capacities1 | 3.84TB, 7.68TB, 15.36TB |
| NAND | 3D eTLC |
| Sequential read/write2 | 7.68TB – 14,000MB/s / 10,000MBs |
| 4k random read/write (IOPS)2 | 7.68TB – 2,800,000 / 500,000 |
| Latency quality of service (QoS)2, 3, 4 | 99% – read/write: <10 µs / < 70 µs |
| Static and dynamic wear levelling | Yes |
| Power loss protection (power caps) | Yes |
| Encryption | Yes – TCG Opal 2.0, AES 256-bit encryption |
| Namespace management support | Yes – 128 namespaces supported |
| Enterprise diagnostics | Telemetry, media wear, temperature, health, etc |
| Endurance (TBW/DWPD)5 | 7.68TB – 14,016TB, 1DWPD (5 years) |
| Power consumption | Idle: 8W Max read: 8.2W Max write: 24W |
| Operating temperature | 0℃ ~ 70℃ |
| Dimensions | 100.50mm x 69.8mm x 14.8mm |
| Weight | 7.68TB – 151.3g |
| Vibration non-operating | 10G peak (10–1000Hz) |
| MTBF | 2 million hours |
| Warranty/support6 | Limited 5-year warranty with free technical support |
| Weight | 0.1 kg |
| Capacity | 8 TB SSD |
| Interface | NVMe SSD Gen 5 |
| Max Sequential Read | Up to 14000 MBps |
| Max Sequential Write | Up to 10000 MBps |
| User Type | Consumer SSD |
