| Technical Details | |
|---|---|
| Form Factor | M.2 2280 |
| Interface | PCIe 4.0 x4 NVMe |
| Capacities | 512GB, 1024GB, 2048GB, 4096GB |
| Controller | Phison E18 |
| NAND | 3D TLC |
| DRAM Cache | Yes |
| Sequential read/write | 512GB – 7,000/3,900MB/s 1024GB – 7,000/6,000MB/s 2048GB – 7,000/7,000MB/s 4096GB – 7,000/7,000MB/s |
| Random 4K read/write | 512GB – up to 450,000/900,000 IOPS 1024GB – up to 900,000/1,000,000 IOPS 2048GB – up to 1,000,000/1,000,000 IOPS 4096GB – up to 1,000,000/1,000,000 IOPS |
| Total Bytes Written (TBW) | 512GB – 400TBW 1024GB – 800TBW 2048GB – 1.6PBW 4096GB – 3.2PBW |
| Power consumption | 512GB – 50mW idle / 0.34W avg / 2.7W (MAX) read / 4.1W (MAX) write 1024GB – 50mW idle / 0.33W avg / 2.8W (MAX) read / 6.3W (MAX) write 2048GB – 50mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write 4096GB – 50mW idle / 0.36W avg / 2.7W (MAX) read / 10.2W (MAX |
| Storage temperature | -40°C~85°C |
| Operating temperature | 0°C~70°C |
| Endurance (TBW) | 80mm x 22mm x 2.21mm (512GB-1024GB) 80mm x 22mm x 3.5mm (2048GB-4096GB) |
| Weight | 512GB-1024GB – 7g 2048GB-4096GB – 9.7g |
| Vibration operating | 2.17G peak (7-800Hz) |
| Vibration non-operating | 20G Peak (20-1000Hz) |
| MTBF | 2,000,000 hours |
| Warranty/Support | Limited 5-year warranty with free technical support |
